Eager Loading of Child Entities in EF Core

Understanding Eager Loading

One of advantages of using EF Core is the ability to manage related data through various loading strategies. There are 3 types of loading the child entities in EF Core:

Eager loading: Preloading related entities as part of the initial query, ensuring all necessary entities are loaded together.
Explicit loading: Manually loading related entities on-demand, providing control over when and what related entities are retrieved.
Lazy loading: Automatically loading related entities as they are accessed, offering a deferred retrieval approach for related entities.

In today's post were are going to have a look on Eager loading. Eager loading is a technique where related entities are loaded from the database as a part of the initial query.

Eager loading is essential for scenarios where you know you'll need related data for every entity retrieved. It avoids the N+1 query problem, reducing the number of round trips to the database.

Using an Include method for loading related entities

Let's have a look on the following entities:

csharp
public class Author
{
    public required Guid Id { get; set; }
    public required string Name { get; set; }
    public required List<Book> Books { get; set; } = new();
}

public class Category
{
    public required Guid Id { get; set; }
    public required string Name { get; set; }
    public required List<Book> Books { get; set; } = new();
}

public class Book
{
    public required Guid Id { get; set; }
    public required string Title { get; set; }
    public required int Year { get; set; }
    public required Author Author { get; set; }
    public required Category Category { get; set; }
}

You can use the Include method in EF Core method to specify the related entities to be included in the query. In the following example, when books are queried, their respective authors are fetched in the same query:

csharp
await using var dbContext = new BooksDbContext();

// Select books with authors
var books = await dbContext.Books
    .Include(b => b.Author)
    .ToListAsync();

You can include multiple related entities in a single query:

csharp
await using var dbContext = new BooksDbContext();

// Select books with authors and categories
var books = await dbContext.Books
    .Include(b => b.Author)
    .Include(b => b.Category)
    .ToListAsync();

In this example, when books are queried, their respective authors and categories are fetched in the same query.

Include method can also be used to load related entities by a collection navigation property:

csharp
await using var dbContext = new BooksDbContext();

var authors = await dbContext.Authors
    .Include(a => a.Books)
    .ToListAsync();

In this example, when books are queried, their respective authors and categories are fetched in the same query.

Multi-level Include

Multi-level eager loading allows to load entities together with their related entities, including relationships of included entities any level deep, in a single query. This can be particularly useful when you have complex data models with multiple levels of relationships.

You can use ThenInclude method to include related entities of the included ones. Let's expand our Book and Author example:

csharp
public class Author
{
    public required Guid AddressId { get; set; }
    public required Address Address { get; set; }
    // Other properties...
}

public class Address
{
    public required Guid Id { get; set; }
    public required string City { get; set; }
    public required string Street { get; set; }
    // Other properties...
}

await using var dbContext = new BooksDbContext();

// Select books with authors and their addresses
var books = await dbContext.Books
    .Include(b => b.Category)
    .Include(b => b.Author)
        .ThenInclude(a => a.Address)
    .ToListAsync();

In this example we are loading Book entities and their related Authors, after that we're loading Authors' Addresses. A query may contain multiple Includes with ThenIncludes, the are no limitations on how deep we can use the these methods.

Auto Include

EF Core 5.0 introduced a feature called AutoInclude which automatically includes certain navigation properties every time the entity is loaded from the database. You can use AutoInclude method in the entity configuration to specify what navigation properties should be loaded with a given entity in every database query. This feature is especially useful for navigation properties that are frequently loaded with the primary entity, simplifying queries and reducing the risk of forgetting to include the related data. Let's have a look on the example how to include Author everytime a book is queried from the database:

csharp
// Put this code in the DbContext or EntityConfiguration class
// where you do the mapping
modelBuilder.Entity<Book>()
    .Navigation(e => e.Author)
    .AutoInclude();

await using var dbContext = new BooksDbContext();

// Authors are automatically included here
var books = await dbContext.Books
    .ToListAsync();

If in some case you don't need to load the AutoIncluded entities, you can use the IgnoreAutoIncludes method to remove the effect of AutoInclude:

csharp
// Put this code in the DbContext or EntityConfiguration class
// where you do the mapping
modelBuilder.Entity<Book>()
    .Navigation(e => e.Author)
    .AutoInclude();

await using var dbContext = new BooksDbContext();

// Select books without auto included authors
var books = await dbContext.Books
    .IgnoreAutoIncludes()
    .ToListAsync();

Include with filtering

In EF Core you can apply filtering on the included entities. This feature allows to load only those related entities that meet a given condition.

csharp
await using var dbContext = new BooksDbContext();

var authors = await dbContext.Authors
    .Include(a => a.Books.Where(b => b.Year >= 2023))
    .ToListAsync();

In this example, the Include method is used with a filtering condition inside a Where clause. This ensures that only books published in the year 2023 and later are included for each author.

EF Core supports the following operations in the Include statement: Where, Skip, Take, OrderBy, OrderByDescending, ThenBy, ThenByDescending.

EF Core has a limitation: each included navigation property can only have one unique set of filtering operations.

Summary

EF Core provides a robust mechanism for handling data relationships through various loading strategies, with eager loading being used most widely. Eager loading allows for the pre-loading of related entities as part of the initial query, ensuring that all necessary data is retrieved in a single round trip to the database. This method is essential for optimizing performance and simplifying data access patterns in applications. In EF Core, eager loading is implemented using the Include method, which specifies the navigation properties to be loaded along with the primary entity. This can be further extended with ThenInclude for multi-level relationships, allowing for deep navigation through related entities.

If some navigations are frequently loaded with the primary entity, simplify the queries using AutoInclude feature. It automatically includes certain navigation properties every time the entity is loaded from the database. EF Core also supports such powerful feature as Include with filtering even for a more control of the related data being loaded.

Hope you find this blog post useful. Happy coding!
